b12n-raylib-jlt — raylib examples in Jolt

Why this is interesting

raylib passes structs by value everywhere, and Chez's foreign-procedure cannot. Nothing here works around that with a C shim — instead each struct gets the treatment its size and contents actually earn on the ABI. Three facts drive every distinctive decision in the binding layer:

Color → a packed :uint

Color is 4 bytes of u8, and a 4-byte all-integer struct travels in one general-purpose register — exactly like a uint32. So every draw call passes color as an int, and no struct marshaling happens at all.
Camera2D / Camera3D → by pointer

A composite larger than 16 bytes is passed indirectly on AArch64 — the caller allocates a copy and passes its address. So the 24-byte Camera2D and 44-byte Camera3D are built in native memory and bound as [:pointer]. This one is AArch64-specific, and the guide says so plainly rather than pretending it ports.
Vector2 / Vector3 → rlgl immediate mode

Small float structs go in floating-point registers, which the pointer trick does not cover. So geometry that takes a Vector2 or Vector3 by value is drawn with rlgl's scalar immediate mode instead — rlVertex3f, rlColor4ub, and the matrix stack for nested transforms.

How it fits together

flowchart LR
  subgraph ex["75 example namespaces"]
    e["pong · boids · tetris
camera-3d · penrose-tiling · …"]
  end
  subgraph shared["net.b12n.raylib-jlt.raylib — one shared layer"]
    kw["keyword-argument drawing API
text! · rect! · circle! · cube!"]
    fb["jolt.ffi/defcfn binds
positional, mirroring C"]
    kw --> fb
  end
  lib["system libraylib
dlopened at runtime, C ABI"]
  e --> kw
  fb -->|"Color as a packed :uint"| lib
  fb -->|"Camera2D/3D by pointer"| lib
  fb -->|"rlgl scalar immediate mode"| lib

Every example is a small namespace over that one shared layer. Adding one touches exactly four places — the source namespace, a deps.edn alias, a check.clj require, and a bb.edn registry row.

What's here

One binding layer

All the FFI binds, the keyword-argument drawing API, and the named color palette live in a single namespace. Examples stay small enough to read in one sitting.

Reads like Clojure, not like C

(rl/circle! :x 400 :y 225 :radius 50 :color rl/MAROON) — positional binds at the boundary, keyword wrappers on top.

Provable without a display

RAYLIB_APP_AUTO_QUIT_MS closes the window on a timer and RAYLIB_APP_SHOT dumps a frame to PNG — so a windowed example can prove itself unattended.

A compile gate over all 75

bb check requires every example namespace headlessly. No window, no JVM, and it catches a broken binding across the whole suite at once.

clj-kondo taught the FFI

A hook rewrites each defcfn into an equivalent defn, so call sites get arity- and return-type-checked instead of producing ~500 false positives.

Not only raylib

The two clock examples call plain libc time() / localtime(), reading struct tm straight out of native memory. Nothing about jolt.ffi is raylib-specific.

Quickstart

bb lib:check       # is the native libraylib installed for this OS/arch?
bb lib:install     # …install it via brew / pacman / apt / dnf / zypper / apk

bb info            # grouped cheat-sheet of every example
bb tetris          # run one (opens a window)
bb run-all 10      # demo reel: every example, 10s each
bb check           # headless compile-check of all 75, no window

Needs jolt (tested against v0.7.16) and a system libraylib. babashka is optional but gives every example a friendly task; without it each one is a joltc -M:<alias> away. Released under the zlib/libpng license — the same one raylib itself uses.

A few of them
